1. Features
- Compatible with 100W and 130W co2 laser tubes.
- Laser engraving responding speed fast with good performance.
- Co2 laser tubes long life.
- simple control with high and low level, TTL level can control the start, stop of the machine, also there is protect switch, checking if it’s water and wind flowing in external.
- Simple laser power control, both 0-5V analog signal and PWM signal can control laser power.
- open circuit protection, when ground connection is in well condition, power supply can work in open circuit in short time, to avoid to be damaged when the tubes is broken, so lengthen power supply life.
- Power supply can be with feedback interface, used for close loop control, also checking the actual working current of the tubes.
- Application: Acrylics engraving, cutting, cloth engraving, cutting, double board and latex engraving and cutting.
2. Technical specification
|
Input |
Input voltage |
220 Vac or 110 Vac (specify when ordering) |
|
Frequency |
47---440 Hz |
|
Surge current |
≤60A( 220 Vac input) |
≤30A(110 Vac input) |
|
Leak current |
≤0.7mA(220 Vac input) |
≤0.4mA(110Vac input) |
|
Output |
Max output voltage |
50 KV dc |
|
Max output current |
38 mA dc |
|
Efficiency |
≥90%（full loading） |
|
M.T.B.F. |
≥10000 hours |
|
Respond time |
≤ 1 mS（from switch signal to output current risen to be 90% of setting current） |
|
Control interface |
TTL input control. ( for details see terminal connections ) |
|
Withstand voltage |
Input – output, input – case: AC1500V 10mA 60s, output negative connected with case. |
|
Protection |
Open circuit in short time（requiring the case connect with ground in well, and avoid positive touch with case） |
|
Environment |
Working temperature （-10~40）℃ ，humidity：≤90% |
|
Cooling |
Forced air cooling |
|
Size |
L×W×H = 325*240*95 (mm) |
|
