NEMA11 Step Motor
|
Electrical Specifications |
|
Series Model |
Step Angle (°) |
Motor Length (mm) |
Rated Current (A) |
Phase Resistance ( Ω ) |
Phase Inductance (mH) |
Holding Torque (N.cm Min) |
Detent Torque (N.cm Max) |
Rotor Inertia (g.cm 2 ) |
Lead Wire (No.) |
Motor Weight (g) |
|
28HS2401 |
1.8 |
28 |
0.6 |
4.2 |
2.2 |
4.5 |
0.3 |
6 |
4 |
105 |
|
28HS2402 |
1.8 |
28 |
0.35 |
12 |
5.8 |
4.5 |
0.3 |
6 |
4 |
105 |
|
28HS3401 |
1.8 |
33 |
0.6 |
5.5 |
3.2 |
6.0 |
0.4 |
8 |
4 |
110 |
|
28HS3402 |
1.8 |
33 |
0.35 |
15 |
9.2 |
6.0 |
0.4 |
8 |
4 |
110 |
|
28HS4401 |
1.8 |
41 |
0.6 |
7.0 |
6.0 |
6.0 |
0.5 |
11 |
4 |
140 |
|
28HS4402 |
1.8 |
41 |
0.35 |
20 |
15 |
6.0 |
0.5 |
11 |
4 |
140 |
|
28HS5401 |
1.8 |
50 |
0.6 |
9.0 |
7.2 |
10 |
0.8 |
13 |
4 |
180 |
|
28HS5402 |
1.8 |
50 |
0.35 |
24 |
18.5 |
10 |
0.8 |
13 |
4 |
180 |
|
|
*Above are our typical type, we can make customized motors according to clients’ special request and drawing. |
|
|
|
